(FM127209XX)
Display Cases | Merchandisers | Food Service | Food Retail
| Rated voltage | 100-240VAC (+/-10%), 50/60Hz |
| Temperature range | -40°C to +50°C |
| Rated current | 0.7 / 0.4A |
| Efficiency | ≤ 70% |
| Output power | 30W Nominal |
| Rated speed | 400 to 2800rpm (+/-1%) |
| Speed selection | 3 discrete programmable speeds. |
| Direction of rotation | CCW, CW, reversible |
| Reverse Speed | Timed reverse programmable options. |
| Motor Protection | Electrically Protected (EP) |
| Ground Protection | Double Insulation |
| Insulation Class | Class B |
| Bearing | 608 sealed ball bearings |
| Approvals | UL / TÜV / CE / RCM / CCC / ATEX* |
| Ingress protection | IP66 |
| Hydrocarbon Compatibility* | EN60335-2-89 ANNEX BB / ATEX |
| 154mm (6") | 172mm (6") | 200mm (8") | 230mm (9") | 254mm (10") | 300mm (12") | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Speed | 22° | 28° | 34° | 22° | 28° | 34° | 22° | 28° | 34° | 22° | 28° | 34° | 22° | 28° | 34° | 22° | 28° | 34° |
| 1300 rpm | ||||||||||||||||||
| 1550 rpm | ||||||||||||||||||
| 1800 rpm |
- Secure rear mount with 4.1mm self tapping screw;
- 3 or 4 hole configuration available;
- Screws available on request.
- Optional foot mount with 25.4 or 28.6mm distances;
- M4 screws.
- 4 side studs for basket mount.
- Three speeds, programmable;
- Timed reverse;
- Control fans using standard off -the-shelf controllers speed via PWM/Voltage/Current. Allows you to fully customize by setting your own desired parameters;
- Select torque or speed control modes;
- Data acquisition available.
- M4 screw with flat washer on female shaft thread or M / 10–32 UNF nut on male shaft thread.
4 stud impeller mount to suit imperial or metric impellers.
